IP69K vs IP68 for Bags: Wash-Down Claims

What IP69K Was Designed For

IP69K comes from ISO 20653, the road-vehicle standard for degrees of protection, and historically from DIN 40050-9. It was written for components mounted on vehicles that get cleaned with high-pressure hot water: engine bay control units, sensors, lighting assemblies and similar hardware. The K suffix marks that road-vehicle origin, and it is not part of the IEC 60529 code at all.

The exposure it models is a wash-down bay. A vehicle or a piece of food-processing equipment is sprayed at close range with hot water at high pressure to remove grease, salt or product residue. The component has to survive that spray without water getting inside, for a short period, from several angles. That is a completely different physical problem from floating in a river for thirty minutes, which is what IPX7 models.

IEC 60529 later added a second-digit value of 9 for high-pressure and high-temperature spray, which is why you will also see IP69 written without the K. The two markings are similar in intent but come from different documents with their own parameters, so a specification should always name which standard was used. Mixing them is the first error we look for when reviewing an industrial RFQ.

• IP69K: road-vehicle origin, defined by ISO 20653, historically DIN 40050-9.
• IP69: the IEC 60529 marking using second digit 9, with its own published parameters.
• Both model a pressure wash-down, not immersion and not rainfall.
• Both assume a rigid, sealed component that stays in one shape under the spray.
• Neither is a higher grade of IP68; the tests are unrelated in mechanism.

The scope assumption in that fourth point is the one that matters for bags. A wash-down test applies a concentrated jet to a surface that is expected to stay put. A fabric panel moves, deflects and transmits the force into the seam behind it. The article is being asked to resist a mechanical attack, not a hydrostatic one, and that is why the soft goods industry rarely uses this rating at all.

For buyers, the first question should always be whether the product will ever see a pressure washer. If the honest answer is no, then IP69K is a marketing artifact rather than a requirement, and spending on it will not improve the product. If the answer is yes, the second question is whether the article should be soft at all, which is addressed further down this page. Our test and documentation protocol starts with those two questions before any apparatus is set up.

The 80 Deg C, 100 Bar Spray Test

The numbers behind the wash-down test are severe by any standard. Water is heated to about 80 degrees Celsius, supplied at roughly 80 to 100 bar, which is 8 000 to 10 000 kilopascals, and delivered at about 14 to 16 litres per minute through a nozzle held roughly 100 to 150 millimetres from the surface. The spray is applied at several angles, commonly 0, 30, 60 and 90 degrees, for about 30 seconds each, with the specimen on a rotating table.

Put that in context. One hundred bar is roughly one hundred atmospheres, or about a thousand metres of water column, and it arrives as a coherent jet rather than as a distributed load. The local pressure at the point of impact is orders of magnitude above anything a bag sees in immersion, where one metre of water is about 0.1 bar. The attack is closer to a cutting tool than to a water test.

Temperature compounds it. Water at 80 degrees Celsius is hot enough to soften many coating polymers and most adhesive films, so the material being attacked is weaker than the material that was qualified at room temperature. That combination, high mechanical force plus reduced material strength, is what makes the test brutal for soft goods and entirely reasonable for a machined aluminium housing.

The pass criterion follows the same logic as other ingress tests: after the spray sequence, the article is opened and examined for water inside. For soft goods you must define that examination yourself, because the standards frame ingress in terms of equipment operation. Our practice is a weighed internal indicator tissue, with zero mass gain as acceptance, plus a photographic record of the closure immediately after the sequence.

One practical note if you do commission this test: the specimen will usually be visibly damaged even when it passes. Coatings can be marked, prints can lift, and hardware can be deformed. Decide in advance what cosmetic damage is acceptable and write that into the specification, otherwise you will have a disagreement with the laboratory about whether a pass counts when the sample looks rough. See our process and validation records for how we document this.

Why Soft Goods Struggle at IP69K

A flexible article fails the wash-down test for three reasons at once: the jet deflects the panel, the force concentrates at the seam, and the heat softens the material. None of those mechanisms appear in an immersion test, which is why a bag that comfortably passes IPX7 at one metre can be destroyed in thirty seconds at 100 bar from 100 millimetres.

Deflection comes first. The jet pushes the fabric inward, the panel bends, and the fold at the seam opens slightly. That opening is exactly where the water goes. In an immersion test the same fold is under gentle, uniform compression and stays closed, so the two tests are not merely different in degree, they produce opposite geometry at the same location.

Seam concentration comes second. A welded seam is a bead of fused coating with a defined width, and a jet arriving at 90 degrees drives water along the edge of that bead. If the weld has any undercut, any cold spot or any contamination at the interface, the jet finds it in seconds. A sewn-and-taped seam is worse: the tape edge is a mechanical lip the jet can lift directly.

1. Panel deflection under the jet opens folds that stay closed under immersion.
2. Force concentrates at the seam bead or at the tape edge, which is the weakest line in the article.
3. Heat at about 80 degrees Celsius softens coatings and adhesive films while the force is applied.
4. Closures deform: a roll-top loosens, a zipper tape separates, a stiffener buckles.
5. Hardware and prints are attacked directly, so cosmetic failure often precedes functional failure.

Closures deserve their own note. A roll-top works by pressing coated fabric against coated fabric, and it resists water because there is a long, tortuous path with contact pressure along it. A high-pressure jet arriving at the mouth of that path does the opposite: it drives water along the path and simultaneously peels the folds apart. There is no roll-top design that reliably survives the wash-down sequence, and any supplier claiming otherwise should be asked for the report.

If your product genuinely needs wash-down, the answer is almost never a better soft bag. It is a rigid case with a gasketed lid, rated to the wash-down condition, with the soft bag used as a liner or as a separate item. Our waterproof bag and case range is structured on that principle: soft articles carry immersion and spray ratings, and wash-down duty goes to rigid construction.

When a Wash-Down Claim Is Genuinely Needed

There are real applications. Food and beverage processing plants wash equipment down daily with hot water and chemical agents, and anything carried into those areas has to survive the same cleaning. Pharmaceutical and medical environments impose similar hygiene routines. Agricultural, mining and waste-handling equipment gets pressure washed, and emergency services decontaminate kit after incidents. In all of these the requirement is genuine and should be specified properly.

Notice what those environments have in common: the article is being cleaned, not used in water. The requirement is about hygiene and about surviving the cleaning routine, so the correct design brief is a smooth, sealed, chemically resistant surface that can be wiped and sprayed. That brief describes a molded case, and it is why the wash-down world is dominated by rigid product.

The test question to ask is who does the washing, how often, and with what. A maintenance team with a 100 bar unit at 80 degrees Celsius is one requirement; a handheld spray at 3 bar and 40 degrees Celsius is quite another. Specifying the full wash-down condition when the real exposure is a gentle rinse adds cost with no benefit, and it is a common consequence of copying a code from a competitor's listing.

Notice that the bottom two rows, which cover the overwhelming majority of bag programmes, do not need wash-down at all. If your product falls into either of them, the correct specification is an immersion or spray rating plus a hydrostatic head figure, and the money saved on validation can go into the closure. Our custom development process starts by placing the product in one of these rows.

There is one hybrid case worth mentioning: a soft bag carried into a wash-down area but stored inside a rigid locker or case during cleaning. In that situation the bag itself only needs a modest spray rating, because it is not the article being washed. Write that into the usage instruction and into the specification, so nobody later assumes the bag was rated for the wash-down it never receives.

Hard Cases vs Soft Bags for Wash-Down

A rigid case survives wash-down for structural reasons. The wall does not deflect under the jet, the lid closes against a continuous gasket with a defined compression, the latches maintain that compression, and there are no seams in the middle of a panel for the jet to attack. Those four features are exactly what a soft bag lacks, and no amount of coating weight substitutes for them.

Where a programme needs both protection and wash-down, the usual architecture is a rigid outer with a soft insert. The outer takes the spray and carries the wash-down rating; the insert carries padding, organisation and shock protection. Specifying the two as separate line items, with separate reports, is the clean way to handle it, and it is how most industrial kit is actually built.

Gasket material is the critical component in that architecture. A continuous silicone or thermoplastic elastomer gasket, seated in a groove that controls compression, holds against both water and repeated cleaning. Specify the gasket by material and by compression, require a compression set figure after thermal aging, and require a replacement interval in the user documentation, because gaskets are consumables no matter how good they are.

• Rigid wall: no deflection, so the jet cannot open a fold or a seam.
• Continuous gasket in a controlled groove: a defined, repeatable seal line.
• Positive latches: maintain compression through vibration and thermal cycling.
• Smooth external surfaces: no crevices where product residue can collect.
• Chemical compatibility: named for the cleaning agents used in the facility.

If a customer insists on a soft article for a wash-down environment, the honest engineering response is a welded TPU shell with no external seams in the spray path, a rigid gasketed access panel rather than a roll-top or zipper, and a defined service life after which the article is retired. That is a significant redesign, and the resulting product is more expensive than a molded case of the same volume, which is worth saying plainly before anyone commits budget.

For the majority of programmes the right answer remains separation: soft bags carry IEC 60529 spray and immersion ratings with a hydrostatic head figure, and wash-down duty goes to a rigid case. Our OEM waterproof bag programme quotes both routes so a buyer can compare them on cost and on service life rather than on a code alone.

Material Behaviour Under Hot Spray

Temperature is the half of this test that buyers underestimate. Water at about 80 degrees Celsius is above the softening region of several polymers used in bag construction. Coatings lose modulus, adhesive films between fabric and film lose bond strength, and thermoplastic components such as stiffeners, buckles and windows lose dimensional stability, all while the jet is applying force.

TPU and PVC behave differently in this region, and the difference drives material selection wherever heat is present. TPU generally retains mechanical properties better at elevated temperature and stays flexible in the cold, while PVC coatings can stiffen in cold conditions and can be more sensitive to heat. Neither is immune to a jet at 100 bar, but the order of survival is clear, and it is one reason technical laminates favour TPU.

Adhesive bonds are the quiet failure. A laminate is fabric held to film by an adhesive layer, and that layer is usually the first thing to lose strength as temperature rises. A weld bead that has excellent peel strength at 20 degrees Celsius can be dramatically weaker at 80 degrees Celsius, which means the seam that survived your room-temperature qualification is not the seam facing the jet. Test peel strength at temperature, not only at ambient.

There is a testing implication worth acting on even for products that never see wash-down. If your market includes hot climates, a container that reaches high internal temperatures, or a product left on a dashboard, then the temperature dependence of your adhesive and your welds matters to ordinary performance. Ask for peel and head figures measured at an elevated temperature, not only at the standard laboratory condition.

We measure weld peel strength across a temperature range for exactly this reason, and the data feeds into the same specification block as the hydrostatic head chart figures. A laminate that holds 10 000 mm at 20 degrees Celsius and loses half of it at 60 degrees Celsius is a different product from one that holds its value, and only a temperature sweep reveals it.

Cost and Failure Modes at IP69K

Chasing a wash-down rating on a soft article is expensive in three places: development, validation and yield. Development costs rise because the closure has to be redesigned around a rigid gasketed panel, which usually means tooling. Validation costs rise because each style and colourway needs its own run on a rig that not every laboratory operates. Yield suffers because a design at the edge of the test fails intermittently, and intermittent failures are the most expensive kind.

The failure modes are worth listing because they tell you where the money goes. Seam bursts at the point of impact, delamination of the laminate, closure deformation, zipper tape separation, window cracking, print removal and hardware distortion are the common ones. Most of them are cosmetic before they are functional, which means the product can look ruined while still passing, and that is a difficult conversation to have with a retail customer.

1. Seam burst: the jet opens a weld bead or lifts a tape edge within seconds.
2. Delamination: the adhesive interlayer fails under combined heat and force.
3. Closure failure: a roll-top peels apart and a zipper tape separates.
4. Window and port failure: rigid inserts and clear panels crack or distort under local load.
5. Cosmetic destruction: prints lift, coatings mark and hardware deforms even on a passing sample.

Compare that with the cost of the alternative. A molded rigid case with a gasketed lid is a known, repeatable construction with mature tooling and predictable validation, and it passes the wash-down condition reliably. For most programmes that need wash-down, the rigid route is cheaper over the life of the product than a soft article engineered to the same duty, once rework, scrap and warranty are counted.

On the commercial side, our frame does not change with the rating. Programmes run at MOQ 500 pcs per style and colourway, sampling in 6 to 10 working days or 12 to 15 when the construction is complex, bulk production in 35 to 50 days, inspection to AQL 2.5 under ISO 2859-1, quoted FOB Xiamen against T/T 30/70. What changes is the validation line, and we quote it separately so you can see what the rating actually costs before you commit.

Writing a Defensible Wash-Down Claim

If the requirement is real, write it precisely. Name the standard, either ISO 20653 for the K marking or IEC 60529 for second digit 9, and name the edition. State the water temperature, the pressure, the flow rate, the nozzle distance, the angles and the duration per angle. State whether the specimen rotated. Then state the pass criterion as a measurement, and state what cosmetic damage is acceptable.

A workable clause reads: Wash-down resistance per ISO 20653, IP69K. Water temperature 80 degrees Celsius, pressure 80 to 100 bar, flow 14 to 16 litres per minute, nozzle distance 100 to 150 millimetres, spray at 0, 30, 60 and 90 degrees for 30 seconds each, specimen on a rotating table. Pass criterion: no mass gain of the internal indicator tissue and no visible moisture on the internal indicator card. Cosmetic marking of the external surface is acceptable provided no coating is removed.

1. Name the standard and edition: ISO 20653 for IP69K, or IEC 60529 for the digit 9 marking.
2. State every parameter: temperature, pressure, flow, distance, angles, duration and motion.
3. Define a measurable pass criterion rather than a visual judgement of the interior.
4. Define acceptable cosmetic damage in advance, because the specimen will usually be marked.
5. Require the full report with setup photographs and instrument readings, not a summary certificate.
6. Add a per-lot verification pull under AQL 2.5 so the claim survives into production.

If the requirement is not real, the correct action is to remove the claim. Copying IP69K from a competitor's listing onto a soft bag creates a claim you cannot substantiate, and wash-down claims are unusually easy for a challenger to test, because the apparatus is common and the failure is dramatic. Replace it with the rating you actually qualified, with its condition printed next to it.

For most bag programmes the defensible final specification is layered: a hydrostatic head figure under ISO 811 with retention thresholds, welded seams with a peel strength requirement, a closure design with a stated number of rolls or a zipper rating, and an IEC 60529 spray or immersion rating on the assembled article. Add a wash-down requirement only for a rigid component, rated separately, and keep the two claims apart on the artwork and in the documentation.

Send us the claim you intend to print, the environment the product will be cleaned in, and your annual volume. We will tell you whether the wash-down route is genuine for your programme, what the rigid alternative costs, and which validation line items are worth paying for. That analysis costs one email and usually settles the question faster than a round of sampling.

Frequently Asked Questions

Q1: What is the difference between IP68 and IP69K?

A: IP68 under IEC 60529 is a continuous immersion claim at a depth and duration the maker declares, suited to dry bags and marine kit. IP69K comes from ISO 20653 for road vehicles and describes a short, close-range spray of water at about 80 degrees Celsius and up to 100 bar. They model completely different exposures and neither one implies the other.

Q2: Which standard defines IP69K?

A: ISO 20653, the road-vehicle standard for degrees of protection, defines IP69K, and the marking historically came from DIN 40050-9. IEC 60529 separately defines a second digit 9 for high-pressure hot spray, written as IP69 without the K. A specification should always name which document was used, because the parameters and the evidence differ.

Q3: What are the actual IP69K test parameters?

A: The wash-down sequence uses water at about 80 degrees Celsius, pressure of roughly 80 to 100 bar, a flow of about 14 to 16 litres per minute, and a nozzle held roughly 100 to 150 millimetres away, sprayed at several angles for about 30 seconds each with the specimen on a rotating table. Exact values should be taken from the standard and the edition you cite.

Q4: Why do soft bags fail the IP69K test?

A: Because the jet deflects the fabric panel, concentrates force at the seam bead or tape edge, and softens coatings and adhesive films at temperature. A roll-top closure is peeled apart by the same jet that would press it shut under immersion. The failure is mechanical and thermal, not hydrostatic, so adding hydrostatic head does not help.

Q5: Is IP69K ever appropriate for a bag?

A: Rarely. It is appropriate for a rigid gasketed case carried into a wash-down environment such as food processing, pharmaceutical, agricultural or mining facilities. For soft bags, the genuine requirements are usually spray or immersion ratings under IEC 60529, and a wash-down claim copied from a listing is a claim nobody can substantiate.

Q6: Does IP69K also mean the product is IP68?

A: No. The codes describe separate tests and passing one does not confer the other. A component can hold a wash-down sequence and fail a prolonged immersion, and a product that passes immersion may be destroyed by a jet. If you need both, commission both tests and mark both codes on the specification with their conditions.

Q7: What happens to coatings at 80 degrees Celsius?

A: Many coating polymers and adhesive films lose mechanical strength well before 80 degrees Celsius, so the material facing the jet is weaker than the material qualified at room temperature. This is why weld peel strength and hydrostatic head should be measured across a temperature range rather than only at the standard laboratory condition.

Q8: What failure modes should I expect when testing a bag to wash-down?

A: Seam bursts at the point of impact, delamination of the laminate, closure deformation, zipper tape separation, window and port cracking, print removal and hardware distortion. Most appear cosmetically before they appear functionally, which means a sample can pass the ingress criterion and still look destroyed, so define acceptable cosmetic damage in advance.

Q9: How should a wash-down claim be written in a specification?

A: Name the standard and edition, then state the temperature, pressure, flow rate, nozzle distance, angles, duration per angle and whether the specimen rotated. Add a measurable pass criterion such as no mass gain of an internal indicator tissue, and state what cosmetic marking is acceptable, because the specimen will usually be marked even when it passes.

Q10: Is a rigid case always better for wash-down duty?

A: For genuine high-pressure hot wash-down, yes. A rigid wall does not deflect, a continuous gasket provides a defined seal line, and latches maintain compression. Soft articles can be engineered toward this duty, but the resulting product is usually more expensive than a molded case of the same volume once rework, scrap and warranty are counted.

Q11: What should I do if a competitor lists IP69K on a soft bag?

A: Ask for the report rather than assuming it is false. Wash-down claims are easy to check because the apparatus is common and the failure is dramatic, so an unsubstantiated claim is a competitive risk for them rather than a benchmark for you. Meanwhile, specify the rating your product genuinely needs and print the condition next to it.

Q12: How much does wash-down validation add to a programme?

A: It adds a separate validation line covering the rig time, the sample destruction and the report, plus development cost if the closure has to be redesigned around a rigid gasketed panel. Quoting that line separately lets you compare it with the cost of a rigid case alternative before committing, which is the comparison that usually settles the decision.

Q13: Can a bag be cleaned with a pressure washer if it is only rated IPX7?

A: It should not be. IPX7 qualifies thirty minutes of shallow immersion, not a concentrated jet at close range, and a pressure washer will usually damage the coating and the closure even where the bag would survive immersion. Instruct end users to rinse with fresh water at low pressure and to avoid directing a jet at the closure.
